Copeland ZPI Series ZPI61KCE-TFD Scroll 62400 BTU/HR 60 Hz 3-460V 410A for Ac
Copeland ZPI Series ZPI61KCE-TFD Scroll 62400 BTU/HR 60 Hz 3-460V 410A for Ac
Prices, shipping costs, and delivery times may vary due to currency and logistics fluctuations. Please contact us for the best price.
Performance
| Evaporator Temp. (°F) | 45.00 | 45 |
|---|---|---|
| Condensing Temp. (°F) | 130.00 | 100 |
| Return Gas Temp. (°F) | 65.00 | 65 |
| Liquid Temp. (°F) | 115.00 | 85 |
| Capacity (BTU/hr) | 62400 | 76700 |
| Power (W): | 5900 | 4180 |
| Current (Amps): | 8.7 | 6.7 |
| EER(BTU/Wh): | 10.6 | 18.35 |
| Mass Flow (lbs/hr): | 920 | 950 |
| Sound Data @ | ||
| Sound Power (dBA): | 75 Avg | 78 Max |
| Vibration mils(peak-peak): | 2.0 Avg | 3.0 Max |
Mechanical
| Displacement (in^3/Rev): | 3.54 |
|---|---|
| Displacement (ft^3/Hr): | |
| Overall Length (in): | 9.70 |
| Overall Width (in): | 9.80 |
| Overall Height (in): | 17.40 |
| Mounting Length (in): | 7.50 |
| Mounting Width (in): | 7.50 |
| Mounting Height (in): | 18.10 |
| Suction Size (in),Type: | 7 / 8 Stub |
| Discharge Size (in),Type: | 1 / 2 Stub |
| Initial Oil Charge (oz): | 57 |
| Oil Recharge (oz): | 60 |
| Oil Type: | 3MA |
| Net Weight (lbs): | 88.8 |
Alternate Applications
1. Why choose your company?
Great service and superior quality is provided all the time.
Packaging & Shipping Packing: Carton, wooden box and pallet, or as customers' requirements.
2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final inspection before shipment.
3. What can you buy from us?
Refrigerator compressor, air compressors, air conditioner refrigerator, compressor, air conditioner parts.
4. How many days for shipping?
By Express: 3–5 working days to your door (DHL, UPS, TNT, FedEx).
By Air: 5–8 working days to your airport.
By Sea: Please advise your port of destination; exact days confirmed by our forwarders.
Reference: Europe & America (25–35 days), Asia (3–7 days), Australia (16–23 days).
5. What services can we provide?
Accepted Delivery Terms: FOB, EXW.
Accepted Payment Currency: USD, EUR, HKD, CNY.
Accepted Payment Type: T/T, L/C, Cash.
Language Spoken: English, Chinese.
