3HP R-22 60 Hz 1 - Phase 265 V Copeland Scroll Refrigeration Compressor ZR34K3-PFJ-522 for Air Conditioning and Industrial Cooling
3HP R-22 60 Hz 1 - Phase 265 V Copeland Scroll Refrigeration Compressor ZR34K3-PFJ-522 for Air Conditioning and Industrial Cooling
常规价格
$175.00 USD
常规价格
促销价
$175.00 USD
单价
单价
Prices, shipping costs, and delivery times may vary due to currency and logistics fluctuations. Please contact us for the best price.
Performance
| Evaporator Temp. (°F) | 45.00 | 45 |
|---|---|---|
| Condensing Temp. (°F) | 130.00 | 100 |
| Return Gas Temp. (°F) | 65.00 | 65 |
| Liquid Temp. (°F) | 115.00 | 85 |
| Capacity (BTU/hr) | 34000 | 40100 |
| Power (W): | 3100 | 2160 |
| Current (Amps): | 11.4 | 8.4 |
| EER(BTU/Wh): | 11 | 18.6 |
| Mass Flow (lbs/hr): | 499 | 515 |
| Sound Data @ | ||
| Sound Power (dBA): | 71 Avg | 76 Max |
| Vibration mils(peak-peak): | 2.0 Avg | 3.0 Max |
Mechanical
| Displacement (in^3/Rev): | 2.82 |
|---|---|
| Displacement (ft^3/Hr): | |
| Overall Length (in): | 9.70 |
| Overall Width (in): | 9.70 |
| Overall Height (in): | 15.20 |
| Mounting Length (in): | 7.50 |
| Mounting Width (in): | 7.50 |
| Mounting Height (in): | 16.00 |
| Suction Size (in),Type: | 3 / 4 Stub |
| Discharge Size (in),Type: | 1 / 2 Stub |
| Initial Oil Charge (oz): | 42 |
| Oil Recharge (oz): | 38 |
| Oil Type: | MIN |
| Net Weight (lbs): | 63.0 |
| Internal Free Volume (in^3): | 161.0 |
Alternate Applications
