5HP Copeland ZP Series ZP61KCE-TFD-496 420 522 Digital Scroll Medium Temperature Compressor
5HP Copeland ZP Series ZP61KCE-TFD-496 420 522 Digital Scroll Medium Temperature Compressor
Prices, shipping costs, and delivery times may vary due to currency and logistics fluctuations. Please contact us for the best price.
Performance
| Evaporator Temp. (°F) | 45.00 | 45 |
|---|---|---|
| Condensing Temp. (°F) | 130.00 | 100 |
| Return Gas Temp. (°F) | 65.00 | 65 |
| Liquid Temp. (°F) | 115.00 | 85 |
| Capacity (BTU/hr) | 61500 | 76000 |
| Power (W): | 5700 | 4010 |
| Current (Amps): | 8.3 | 6.3 |
| EER(BTU/Wh): | 10.8 | 19 |
| Mass Flow (lbs/hr): | 910 | 945 |
| Sound Data @ | ||
| Sound Power (dBA): | 74 Avg | 79 Max |
| Vibration mils(peak-peak): | 2.0 Avg | 3.0 Max |
Mechanical
| Displacement (in^3/Rev): | 3.54 |
|---|---|
| Displacement (ft^3/Hr): | |
| Overall Length (in): | 9.70 |
| Overall Width (in): | 9.90 |
| Overall Height (in): | 17.40 |
| Mounting Length (in): | 7.50 |
| Mounting Width (in): | 7.50 |
| Mounting Height (in): | 18.20 |
| Suction Size (in),Type: | 1 1 / 4 Rotalock |
| Discharge Size (in),Type: | 1 Rotalock |
| Initial Oil Charge (oz): | 56 |
| Oil Recharge (oz): | 52 |
| Oil Type: | 3MA |
| Net Weight (lbs): | 88.8 |
| Internal Free Volume (in^3): | 274.0 |
Alternate Applications
| Refrigerant | Voltage | Phase | Frequency | Application |
|---|---|---|---|---|
| R-410A HFC | 380/420 | 3 | 50 | Air Conditioning |
| Suction Connection | Stub |
|---|---|
| Suction Size | 7/8" |
| Discharge Connection | Stub |
| Discharge Size | 1/2" |
| Electrical Connection | Terminal Block |
| Mounting Assembly | Not Available |
| Tandem Ready | Yes |
|---|
| Suction Connection | Stub |
|---|---|
| Suction Size | 7/8" |
| Discharge Connection | Stub |
| Discharge Size | 1/2" |
| Electrical Connection | |
| Mounting Assembly | Not Available |
| Sight Glass | |
| Crankcase Heater | |
| Schrader Valve | |
| Tandem Ready | Yes |
| Suction Connection | Stub |
|---|---|
| Suction Size | 7/8" |
| Discharge Connection | Stub |
| Discharge Size | 1/2" |
| Electrical Connection | Terminal Block |
| Mounting Assembly | Not Available |
| Suction Connection | Stub |
|---|---|
| Suction Size | 7/8" |
| Discharge Connection | Stub |
| Discharge Size | 1/2" |
| Electrical Connection | Molded Plug |
| Mounting Assembly | Not Available |
