HOT Sale Danfoss SM161T4VC SM160T4CC SM160T4RC SM161T9VC 12HP 13HP for Air Conditioning Freezer Scroll Compressor
HOT Sale Danfoss SM161T4VC SM160T4CC SM160T4RC SM161T9VC 12HP 13HP for Air Conditioning Freezer Scroll Compressor
Prices, shipping costs, and delivery times may vary due to currency and logistics fluctuations. Please contact us for the best price.
| Gross weight | 102 Kilogram |
| Net weight | 90 Kilogram |
| Volume | 0.23 Cubic meter |
| Type | SM160 |
| Product group | Hermetic compressors |
| Product Name Description | Scroll compressor SM |
| Family | SM |
| Fitting standard | ODF |
| Frequency [Hz] | 60 |
| Gauge port HP | None |
| Gauge port LP | Schrader |
| Glass mounting | Threaded |
| Glass torque [Nm] | 50 N-m |
| GP LP torque [Nm] | 15 N-m |
| High Side TS Max | 150 °C |
| High Side TS Min | -35 °C |
| MMT | 61 A |
| Model number | SM160T3CC |
| Motor protection | Internal thermostat, ext. overload protector needed |
| Mounting torque [Nm] | 21 N-m |
| Network power supply [V/Ph/Hz] | 208-230/3/60 |
| Number of starts per hour [Max] | 12 |
| Oil charge [L] | 4 L |
| Oil drain | 1/4'' flare |
| Oil drain torque [Nm] | 35 N-m |
| Oil equalization | 3/8'' flare SAE |
| Oil equalization torque [Nm] | 48 N-m |
| Oil reference | 160P |
| Oil type | Mineral |
| Packaging height [mm] | 671 mm |
| Packaging length [mm] | 470 mm |
| Packaging weight [Kg] | 671 kg |
| Packaging width [mm] | 370 mm |
| Packing format | Single pack |
| Packing quantity | 1 |
| Phase | 3 |
| Power connections | Screw 4.8 mm |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Refrigerant charge [kg] [Max] | 12.5 kg |
| Refrigerants | R22 |
| Rotational speed at 60Hz [rpm] | 3500 rpm |
| SCIP dossier no. | 58968d52-aa4c-4c0c-9aee-1ce6a31dfbd1 |
| SCIP dossier product name | SM115/SM125/SM160/SM175/SM185/SZ115/SZ125/SZ160/SZ175/SZ185/SY185 |
1. Why choose your company?
Great service and superior quality is provided all the time.
Packaging & Shipping Packing: Carton, wooden box and pallet, or as customers' requirements.
2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final inspection before shipment.
3. What can you buy from us?
Refrigerator compressor, air compressors, air conditioner refrigerator, compressor, air conditioner parts.
4. How many days for shipping?
By Express: 3–5 working days to your door (DHL, UPS, TNT, FedEx).
By Air: 5–8 working days to your airport.
By Sea: Please advise your port of destination; exact days confirmed by our forwarders.
Reference: Europe & America (25–35 days), Asia (3–7 days), Australia (16–23 days).
5. What services can we provide?
Accepted Delivery Terms: FOB, EXW.
Accepted Payment Currency: USD, EUR, HKD, CNY.
Accepted Payment Type: T/T, L/C, Cash.
Language Spoken: English, Chinese.
